OMICRON DIRANA

DS-PDC+ dielectric insulation analyzer

Easy determination of insulation’s condition

DIRANA uses dielectric frequency response (DFR) analysis in order to determine the condition of high-voltage insulation systems such as those in power transformers, bushings, cables and generators.

It automatically analyses and determines the water content and the oil conductivity in different types of cellulose insulation. You can test assets filled with mineral oil, natural and synthetic ester as well as air or vacuum. The measurement results are shown in categories defined by IEC 60422.

Combining advantages

DIRANA combines the advantages of frequency-domain and time-domain spectroscopy. This combination enables fast measurements covering the largest frequency range on the market. DIRANA is the only device in the industry which uses this combination and an advanced polarization depolarization current version, called PDC+. This ensures the shortest measurement time on all assets at any temperature.

Simplified testing

DIRANA is operated with the Primary Test Manager™ (PTM) software, the ideal solution for diagnostic testing, condition assessment and easy data management. PTM automatically generates test plans based on the nameplate data. The measurement results obtained are automatically compared and evaluated according to international standards or customized limit values. In addition, PTM offers smart features for data management and easy reporting.

Key features

Compact and rugged all-in-one test set Revolutionary new FDS & PDC+ algorithm for up to 20x faster testing: Less than 2 hours for a full 10 µHz – 1 kHz frequency sweep Fully automatic parameter setting and improved moisture assessment for optimal results Support of ester-filled assets due to new databases for synthetic and natural ester Guided workflow for test setup, execution and assessment for easy analysis without expert knowledge.

Applications

With DIRANA you can test assets filled with mineral oil, natural and synthetic ester as well as air or vacuum. Commonly tested assets are:

• Power transformers
• Instrument transformers
• Bushings

Additionally, dielectric measurements are available for condition diagnosis of other assets, such as:

• Rotating machines
• Resin-bonded paper (RBP), resin-impregnated paper (RIP) and resin-impregnated synthetic (RIS) bushings
• Cables
